Electro UV CRT

FEATURES, FUNCTIONS AND SPECIFICATIONS:
• Norm: AMATEUR RADIO (restriction : in emission use with amator radio certificate obligatory)
• Mode: FM ( Wide/Narrow ) RX : 87.5-108MHz
• Frequency range:
…RX: 144-146 MHz
…TX : 430-440 MHz
• Power :
…LOW: 5W
…MIDDLE: 10W
…HIGH: 20W
• Input voltage: 13,8V DC
• Memories: 500 channels
• Channel spacing: 12.5 / 25 KHz
• Step of increment: 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 KHz
• Working: UU / UV / VU / VV
• RELAY MOD / OFFSET: allows to enter a relay with two different frequency
• TONE BURSt: 1000Hz / 1450Hz / 1750Hz / 2100Hz
• SCRAMBLER: (1 to 11)
• CTCSS / DCS (encoder/decoder): 52 CTCSS / 1024 DCS : sub-audio code to activate repeater like selective tone
• DTMF (encoder): tones selected to activate repeater, internet gateway and other items - 2TONS - 5 TONS
• VOX function: this feature triggers your microphone sound (hands free)
• TOT function : time out timer
• SCAN function: automatic search of busy channels
• COMPANDER function: TX with a clear voice
• TX/OFF function: forbidding emission
• REVERSE function: the current channel RX frequency will be switched to TX frequency
• TALK AROUND function: switch RX/TX frequencies and CTCSS/DCS code to avoid using repetear
• Noise Reduction
• Key Beep
• SQUELCH mode
• LCD brightness
• Channel display
• REPEATER
• DTMF transmit time
• Options: Programming cable + software
• Size: 124 x 101 x 36 mm
• Weight: 0.45 kg
• Warranty: 2 years

PACKING INCLUDES:
1 Pc of Transceiver
1 Pc of Microphone
1 Pc of Fixing Bracket
1 Pc of Power cable with CLP
1 pc of User Manual in French
1 Pc of User Manual in English.
